Control Acceso Facial mas Temperatura, Hikvision Asistencia, Mon 7", 50K Rostro, 2 Cam 2Mpx Gigabit, Wiegand.

DS-K1T671TM-3XF

Face Recognition Terminal

DS-K1T671TM-3XF face recognition terminal is a kind ofaccess control device integrated with fever screeningfunction. It can fast taking skin-surface temperature andupload abnormal temperature event to the center, whichcan be widely applied in multiple scenarios, such asenterprises, stations, dwellings, factories, schools, campusand so on.

Available Model

DS-K1T671TM-3XF

Features•Supports Vanadium Oxide uncooled sensor to measure target's temperature•Temperature measuring range: 30 °C to 45 °C (86 °F to 113 °F), accuracy: ± 0.5 °C without black body calibration•Recognition distance: 0.3 to 2 m•Fast temperature measurement mode: Detects face and takes skin-surface temperature without identityauthentication.•Multipleauthentication modes are available: card and temperature, face and temperature, card and face andtemperature, etc.•Face mask wearing alertIf the recognizing face does not wear a mask, the device will prompt a voice reminder. At the same time, theauthentication or attendance is valid.•Forced mask wearing alertIf the recognizing face does not wear a mask, the device will prompt a voice reminder. At the same time, theauthentication or attendance will be failed.•Displays temperature measurement results on the authentication page•Triggers voice prompt when detecting fever•Configurable door status (open/close) when detecting fever•Transmits online and offline temperature information to the client software via TCP/IP communication and saves the dataon the client software•Face recognitionduration＜ 0.2 s/User; face recognition accuracy rate ≥ 99%•50,000 face capacity, 50,000 card capacity, and 100,000 event capacity.

•Suggested height for face recognition: between 1.4 m and 1.9 m•Supports 6 attendance status, including check in, check out, break in, break out, overtime in, overtime out•Watchdog design and tamper function•Audio prompt for authentication result•NTP, manually timesynchronization, and auto synchronization•Connects to external access controller or Wiegand card reader via Wiegand protocol•Connects to secure door control unit via RS-485 protocol to avoid the door opening when the terminal is destroyed•Imports and export data to the device from the client software*Biometric recognition products are not 100% applicable to anti-spoofing environments. If you require a higher securitylevel, use multipleauthentication modes

•Suggested height for face recognition: between 1.4 m and 1.9 m•Supports 6 attendance status, including check in, check out, break in, break out, overtime in, overtime out•Watchdog design and tamper function•Audio prompt for authentication result•NTP, manually timesynchronization, and auto synchronization•Connects to external access controller or Wiegand card reader via Wiegand protocol•Connects to secure door control unit via RS-485 protocol to avoid the door opening when the terminal is destroyed•Imports and export data to the device from the client software*Biometric recognition products are not 100% applicable to anti-spoofing environments. If you require a higher securitylevel, use multipleauthentication modes.

Specifications

Model DS-K1T671TM-3XF

Operation system      Linux

Temperature measurement

Sensor      Vanadium Oxide uncooled sensor

Resolution      120 × 160

Frame rate      25 fps

Temperature range      30 °C to 45 °C (86 °F to 113 °F)

Temperature accuracy      ±0.5 °C, without black body calibration

Measuring distance      0.3 to 2 m

Screen      Screen7 inch touch

Screen Ratio      16:9

Resolution      1024 × 600

Camera      2 MP dual-lens camera, WDR

Indicator      Support

Face      Recognition mode      Face: 1:1 and 1:N

Face capacity      50,000

Face recognition duration      ＜ 0.2 s per person

Face recognition distance      0.3 to 2 mCard

Card capacity      50,000

Card type      M1 card

Card presentingduration      ＜ 1 s

Card presenting distance      0 to 5 cm

Event capacity      100,000

InterfaceNetwork × 1,

RS-485 × 1,

Wiegand × 1,

USB × 2,

alarm output× 1,

alarm input × 2,

lock ×1,

door contact × 1,

exit button ×1,

tamper × 1

Network10/100/1000 Mbps self-adaptive

Wi-Fi/ NO

TamperSupport

ModelDS-K1T671TM-3XF

OtherWorking voltage12 VDC/2 A

Working temperature0 °C to 50 °C (32 °F to 122 °F)

Working humidity10 to 90% (No condensing)ApplicationIndoor

Application environmentIndoor and windless environment use only

*Exposing the equipment to direct sun light, low ventilation or heat source such as heater or radiator is forbidden(ignorance can cause fire danger).
